| Product Code | Dimensions | Colour | Suitable Products* | Downloads |
|---|---|---|---|---|
| HANECO-DC | black |
*For specific product SKU compatability check the datasheet
DALI Converter(Highbays)
Highbays and Lowbays
DALI Converter
Overview
The Haneco‑DC CU Bridge Series is a high‑performance DALI‑to‑0–10V dimming converter designed to deliver reliable, flexible and energy‑efficient lighting control across a wide range of commercial and industrial applications. With IP67 protection, low standby power and compatibility with multiple DALI standards, it ensures robust performance even in demanding environments.
Details
The Haneco‑DC CU Bridge Series is engineered to translate DALI dimming commands into a precise 0–10V dimming output, offering seamless integration with modern LED lighting systems. Designed for maximum compatibility, it supports IEC 62386 Parts 101, 102, 206 (DT5), 207 (DT6) and DALI Part 251 (DT50), making it suitable for a wide range of smart lighting applications.
Built with a durable IP67‑rated enclosure, the CU Bridge ensures reliable operation in both indoor and outdoor environments. Installers benefit from flexibility, with support for cable outer diameters between 5mm and 8mm, and the option to select a logarithmic or linear dimming curve (logarithmic by default).
With exceptionally low standby power—just 2.8mA—and sink capability of up to 50mA, the Haneco‑DC CU Bridge Series delivers efficient, stable and flicker‑free dimming for various LED engines and fixture types.
One SKU supports multiple fixture requirements, simplifying inventory management and improving installation efficiency. Powered directly through the DALI bus, it eliminates the need for additional power supplies.
