| Product Code | Wattage | Lumen Output | Efficacy | CCT | Dimensions | Downloads |
|---|---|---|---|---|---|---|
| OVL145R-DIM | 10 W 14 W | 1037 / 1186 / 1115 lm 1348 / 1554 / 1457 lm | 93 / 111 / 100 lm/W 93 / 113 / 100 lm/W | 3000 / 4000 / 5700 K | Ø145 x 61 mm | |
| OVL165R-DIM | 13 W 18 W | 1435 / 1619 / 1549 lm 1767 / 1994 / 1908 lm | 100 / 118 / 108 lm/W 100 / 119 / 109 lm/W | 3000 / 4000 / 5700 K | Ø165 x 63 mm | |
| OVL200R-DIM | 15 W 20 W | 1309 / 1484 / 1405 lm 1805 / 2050 / 1933 lm | 98 / 118 / 105 lm/W 99 / 120 / 106 lm/W | 3000 / 4000 / 5700 K | Ø200 x 68 mm | |
| OVL230R-DIM | 23 W 30 W | 2148 / 2479 / 2332 lm 2823 / 3273 / 3073 lm | 99 / 123 / 109 lm/W 99 / 124 / 109 lm/W | 3000 / 4000 / 5700 K | Ø230 x 75 mm |
OVOLO
Downlights
Impressive, classic and all-purpose
Applications
Awnings,Bathrooms,Boardroom / Meeting Rooms,Education Facilities,Entrance,Food Courts,Function Areas,Medical Facilities,Hallways,Offices,Retail Spaces,Showrooms,Staircase
Overview
The versatile OVOLO series combines practical functionality with impressive features. Due to its IP63 rating, this allrounder is ideal for both indoor and outdoor applications. This ultra lightweight downlight comes in a range of sizes which allows for direct replacement of compact fluorescent and metal halide products.
Details
Introducing the OVOLO series, a versatile lighting solution that brings together practical functionality and impressive features. With its painted aluminium housing, the OVOLO series not only delivers exceptional performance but also adds a touch of elegance to any space.
Experience the freedom of tritone colour changeable capability, allowing you to create the perfect lighting atmosphere to suit your preferences. Whether you desire a warm and inviting glow or a vibrant and dynamic ambience, the OVOLO series offers a spectrum of colour options to enhance any environment.
Choose from a variety of sizes available in the OVOLO series, providing you with flexibility in design and installation. Its design allows for direct replacement of compact fluorescent and metal halide products, making it an ideal choice for retrofitting projects and seamless upgrades.
With its high ambient temperature rating of 40°C, the OVOLO series thrives even in challenging environments, ensuring reliable performance and longevity. Its IP63 rating makes it suitable for both indoor and outdoor applications, adding versatility to its impressive range of capabilities.For advanced control and integration, the OVOLO series offers an optional DALI model. This enables seamless compatibility with sophisticated lighting systems, allowing you to harness the power of intelligent lighting control.
Discover the versatility of the OVOLO series—a lightweight, high-performance downlight that combines functionality, style, and convenience. Elevate your lighting experience with the OVOLO series, a reliable and adaptable choice for both indoor and outdoor applications.Features & Benefits
Tritone colour changeable
Provides the choice of light hues from a single luminaire
Power switchable
Adjust the light to suit the requirements
Recessed diffuser
Minimises glare and enhancing visual comfort
Optional DALI model available
Designed to integrate into a larger ecosystems.
Large power options
Offering the right amount of light for the application
Dimmable driver
Adjustable brightness to improve comfort
Flicker-free driver
Increase productivity and lowers eye strain
IC-4 rating (ta 25°C) (Model Dependent)
Allows for covered and abutted installations
IP63 rating
Ideal for a wide variety of indoor applications
Choice of sizes to choose from
Adaptable to suit various requirements
High Colour Rendering Index (CRI)
True colour definition to highlight natural colour
High ambient temperature rating (>40°C)
Long lasting in hot environments
