| Product Code | Wattage | Lumen Output | Efficacy | CCT | Dimensions | Downloads |
|---|---|---|---|---|---|---|
| STAX70WPLUS | 30W 50W 70W | 4,182 / 4,238 / 4,245 lm 6,550 / 6,842 / 6,799 lm 9,034 / 9,898 / 9,624 lm | 139 / 144 / 143 lm/W 141 / 151 / 146 lm/W 129 / 146 / 137 lm/W | 3000 / 4000 / 5000 K | 263 x 311 x 57mm | |
| STAX150WPLUS | 100W 120W 150W | 13,982 / 14,664 / 14,465 lm 16,443 / 17,536 / 16,924 lm 20,759 / 21,859 / 20,761 lm | 138 / 150 / 142 lm/W 135 / 148 / 138 lm/W 133 / 146 / 133 lm/W | 3000 / 4000 / 5000 K | 331 x 391 x 57mm | |
| STAX300WPLUS | 200W 250W 300W | 27,453 / 30,165 / 29,853 lm 32,479 / 35,725 / 34,842 lm 34,803 / 39,305 / 38,113 lm | 129 / 148 / 139 lm/W 125 / 145 / 134 lm/W 117 / 141 / 128 lm/W | 3000 / 4000 / 5000 K | 417 x 487 x 67mm | |
| STAX200WPLUS | 150W 170W 200W | 20,999 / 23,026 / 22,758 lm 23,151 / 25,536 / 24,811 lm 25,597 / 28,807 / 27,597 lm | 138 / 158 / 149 lm/W 135 / 155 / 143 lm/W 130 / 152 / 139 lm/W | 3000 / 4000 / 5000 K | 367 x 429 x 60mm |
STAXPLUS
Spotlights and Floodlights
Versatile and effective.
Applications
Shed, Side of Building, Temporary Installations, General Industrial, Area Lighting, Carparks, Carports
Overview
STAX PLUS is a high‑performance asymmetric LED floodlight designed for precise, uniform and low‑glare illumination across sports facilities, industrial sites and outdoor areas. Its advanced optical design minimises spill light while maximising efficiency, and its robust, weather‑resistant construction ensures long‑lasting reliability in demanding environments.
Details
STAX PLUS is a next‑generation, high‑performance asymmetric LED floodlight designed to deliver precise, uniform and low‑glare illumination across even the most demanding environments. Leveraging advanced asymmetric optics commonly used in professional sports and area floodlighting, it ensures controlled light distribution that reduces spill light, enhances visual comfort and improves overall lighting uniformity.
Engineered for maximum efficiency and long‑term reliability, STAX PLUS provides superior illumination for sports fields, industrial facilities, carparks and large outdoor spaces. Its optical performance aligns with high‑quality sports and industrial floodlights known for producing consistent brightness, minimising obtrusive light and supporting compliance with modern environmental lighting standards. This makes STAX PLUS ideal for locations requiring both high visual clarity and responsible light control.
Built on a robust, weather‑resistant platform, STAX PLUS performs reliably in harsh climates and high‑usage environments, similar to the durable construction found in premium stadium and industrial-grade floodlights. Its strong thermal management, stable output and efficient LED technology ensure dependable operation while reducing long‑term maintenance and energy costs. Whether improving visibility for athletes or enhancing safety across industrial zones and outdoor precincts, STAX PLUS sets a new benchmark for performance, durability and sustainable lighting excellence
Key features for the range include:
- High-Performance Asymmetric Design – Ensures precise and uniform light distribution.
- Energy-Efficient & Durable – Built to withstand tough conditions while reducing operational costs.
- Versatile Applications – Perfect for sports, industrial, and outdoor environments.
- Advanced Optics – Delivers optimal brightness and clarity where it matters most.
Features & Benefits
Tritone colour selectable
Provides the choice of light hues from a single luminaire
IP66 and IK08 rating
Durable construction and performance for outdoor areas
Power switchable
Adjust the light to suit the requirements
Choice of sizes to choose from
Adaptable to suit various requirements
Exceptional performance
High efficacy rating to promote energy saving
Extensive model range
Covers a diverse range of applications
Low profile design
Suitable for very shallow ceiling spaces
Sleek diecast aluminium housing
Improve asethetic design whilst improving thermal characteristics
Integrated driver with cable and plug
Provides quick and easy installation
Adjustable gimbal
Increased versatility to direct light where it is required
High ambient temperature rating (>40°C)
Long lasting in hot environments
Optional plug in motion sensor
Retrofittable option to assist in energy usage or security lighting
Easily adjustable
Simple installation and adjustability
Large power options
Offering the right amount of light for the application
