| Product Code | Wattage | Lumen Output | Efficacy | CCT | Dimensions | Downloads |
|---|---|---|---|---|---|---|
| VISTA-EV12 | 20 W 26 W 34 W 40 W | 2609 / 2756 / 2666 lm 3240 / 3507 / 3306 lm 3998 / 4491 / 4148 lm 4561 / 4996 / 4547 lm | 135 / 148 / 136 lm/W 130 / 146 / 131 lm/W 119 / 140 / 121 lm/W 118 / 137 / 119 lm/W | 4000 / 4700 / 5700 K | 1205 x 64 x 65 mm | |
| VISTA-EV12-MS | 20 W 40 W | 2223 / 2362 / 2332 lm 4079 / 4458 / 4197 lm | 131 / 143 / 135 lm/W 115 / 131 / 117 lm/W | 4000 / 4700 / 5700 K | 1205 x 64 x 65 mm | |
| VISTA-EV12-EM | 20 W 40 W | 2584 / 2718 / 2609 lm 4526 / 4952 / 4618 lm | 117 / 127 / 119 lm/W 108 / 124 / 110 lm/W | 4000 / 4700 / 5700 K | 1205 x 64 x 65 mm | |
| VISTA-EV12-EM-MS | 20 W 40 W | 2253 / 2393 / 2336 lm 4044 / 4539 / 4221 lm | 126 / 1138 / 130 lm/W 102 / 120 / 106 lm/W | 4000 / 4700 / 5700 K | 1205 x 64 x 65 mm | |
| VISTA-EV06 | 10 W 13 W 17 W 20 W | 1310 / 1383 / 1335 lm 1622 / 1746 / 1671 lm 2054 / 2254 / 2108 lm 2313 / 2582 / 2383 lm | 124 / 135 / 125 lm/W 121 / 135 / 123 lm/W 115 / 132 / 116 lm/W 111 / 129 / 111 lm/W | 4000 / 4700 / 5700 K | 605 x 64 x 65 mm | |
| VISTA-EV06-EM | 20 W | 2354 / 2627 / 2404 lm | 98 / 113 / 98 lm/W | 4000 / 4700 / 5700 K | 605 x 64 x 65 mm | |
| VISTA-EV12-BK | 20 W 26 W 34 W 40 W | 2609 / 2756 / 2666 lm 3240 / 3507 / 3306 lm 3998 / 4491 / 4148 lm 4561 / 4996 / 4547 lm | 135 / 148 / 136 lm/W 130 / 146 / 131 lm/W 119 / 140 / 121 lm/W 118 / 137 / 119 lm/W | 4000 / 4700 / 5700 K | 1205 x 64 x 65 mm | |
| VISTA-EV12-MS-BK | 20 W 40 W | 2223 / 2362 / 2332 lm 4079 / 4458 / 4197 lm | 131 / 143 / 135 lm/W 115 / 131 / 117 lm/W | 4000 / 4700 / 5700 K | 1205 x 64 x 65 mm | |
| VISTA-EV12-EM-BK | 20 W 40 W | 2584 / 2718 / 2609 lm 4526 / 4952 / 4618 lm | 117 / 127 / 119 lm/W 108 / 124 / 110 lm/W | 4000 / 4700 / 5700 K | 1205 x 64 x 65 mm | |
| VISTA-EV12-EM-MS-BK | 20 W 40 W | 2253 / 2393 / 2336 lm 4044 / 4539 / 4221 lm | 126 / 1138 / 130 lm/W 102 / 120 / 106 lm/W | 4000 / 4700 / 5700 K | 1205 x 64 x 65 mm | |
| VISTA-EV06-BK | 10 W 13 W 17 W 20 W | 1310 / 1383 / 1335 lm 1622 / 1746 / 1671 lm 2054 / 2254 / 2108 lm 2313 / 2582 / 2383 lm | 124 / 135 / 125 lm/W 121 / 135 / 123 lm/W 115 / 132 / 116 lm/W 111 / 129 / 111 lm/W | 4000 / 4700 / 5700 K | 605 x 64 x 65 mm | |
| VISTA-EV06-EM-BK | 20 W | 2354 / 2627 / 2404 lm | 98 / 113 / 98 lm/W | 4000 / 4700 / 5700 K | 605 x 64 x 65 mm |
VISTAEVO
Indoor Battens
Well rounded LED batten.
Applications
Garage, Shed, Offices, Education Facilities, Storage Facilities, Storage Rooms, Manufacturing Facilities, Temporary Installations
Overview
VISTA EVO is a sleek new concept on a traditional design. This well rounded batten may have a small footprint but packs all the features that is expected from a VISTA product. Available in black or white, 2ft or 4ft and optional emergency and motion sensors round out this simple yet reliable LED batten.
Details
VISTA EVO, a revolutionary LED batten that seamlessly blends modern aesthetics with the trusted functionality of VISTA products. Despite its well-rounded, low-profile design, VISTA EVO packs a punch with an impressive feature set. Choose from black or white finishes and 2ft or 4ft lengths for effortless integration into any environment.
VISTA EVO offers exceptional versatility with its tritonal color temperature selection and adjustable power output, allowing you to create the perfect lighting ambience for any space. The user-friendly power switchable function and simple 2-piece flip-open design ensure effortless operation and installation, saving you valuable time.
The VISTA EVO's painted aluminium housing guarantees long-lasting performance and a premium look and feel, while the extensive model range minimizes the number of SKUs you need to manage. For added functionality, optional emergency backup and motion sensors transform VISTA EVO into a comprehensive lighting solution. Experience the perfect blend of style, performance, and ease of use with VISTA EVO.
Features & Benefits
Tritone colour selectable
Provides the choice of light hues from a single luminaire
Choice of colour finishes
Blend fitting into the existing environment seemlessly
Power switchable
Adjust the light to suit the requirements
Modernised design
Provides high end appearance
Easy terminal block access
Aids in improving the installation process
Emergency back up battery (Model Dependent)
Provides safety in case of power outages
Sensor activation (Model Dependent)
Improve power conservation when not in use
Extensive model range
Covers a diverse range of applications
Narrow design
Built to be aesthetic with minimal space
Simple 2 piece flip-open design
Provides quick & easy installation
