| Product Code | Wattage | Lumen Output | Efficacy | CCT | Dimensions | Downloads |
|---|---|---|---|---|---|---|
| FXDL6W-3K2M | 6W/m | 760 lm per metre | 110 lm/W | 3000 K | 2,000 x 8 x 3 mm | |
| FXDL6W-4K2M | 6W/m | 760 lm per metre | 110 lm/W | 4000 K | 2,000 x 8 x 3 mm | |
| FXDL6W-6K2M | 6W/m | 760 lm per metre | 110 lm/W | 6000 K | 2,000 x 8 x 3 mm | |
| FXDL6W-3K5M | 6W/m | 760 lm per metre | 110 lm/W | 3000 K | 5,000 x 8 x 3 mm | |
| FXDL6W-4K5M | 6W/m | 760 lm per metre | 110 lm/W | 4000 K | 5,000 x 8 x 3 mm | |
| FXDL6W-6K5M | 6W/m | 760 lm per metre | 110 lm/W | 6000 K | 5,000 x 8 x 3 mm | |
| FXDL6W-3K10M | 6W/m | 760 lm per metre | 110 lm/W | 3000 K | 10,000 x 8 x 3 mm | |
| FXDL6W-4K10M | 6W/m | 760 lm per metre | 110 lm/W | 4000 K | 10,000 x 8 x 3 mm | |
| FXDL6W-6K10M | 6W/m | 760 lm per metre | 110 lm/W | 6000 K | 10,000 x 8 x 3 mm | |
| FXDL9W-3K2M | 9W/m | 1020 lm per metre | 110 lm/W | 3000 K | 2,000 x 8 x 3 mm | |
| FXDL9W-4K2M | 9W/m | 1020 lm per metre | 110 lm/W | 4000 K | 2,000 x 8 x 3 mm | |
| FXDL9W-6K2M | 9W/m | 1020 lm per metre | 110 lm/W | 6000 K | 2,000 x 8 x 3 mm | |
| FXDL9W-3K5M | 9W/m | 1020 lm per metre | 110 lm/W | 3000 K | 5,000 x 8 x 3 mm | |
| FXDL9W-4K5M | 9W/m | 1020 lm per metre | 110 lm/W | 4000 K | 5,000 x 8 x 3 mm | |
| FXDL9W-6K5M | 9W/m | 1020 lm per metre | 110 lm/W | 6000 K | 5,000 x 8 x 3 mm | |
| FXDL9W-3K10M | 9W/m | 1020 lm per metre | 110 lm/W | 3000 K | 10,000 x 8 x 3 mm | |
| FXDL9W-4K10M | 9W/m | 1020 lm per metre | 110 lm/W | 4000 K | 10,000 x 8 x 3 mm | |
| FXDL9W-6K10M | 9W/m | 1020 lm per metre | 110 lm/W | 6000 K | 10,000 x 8 x 3 mm | |
| FXDL14W-3K2M | 14W/m | 1470 lm per metre | 110 lm/W | 3000 K | 2,000 x 8 x 3 mm | |
| FXDL14W-4K2M | 14W/m | 1470 lm per metre | 110 lm/W | 4000 K | 2,000 x 8 x 3 mm | |
| FXDL14W-6K2M | 14W/m | 1470 lm per metre | 110 lm/W | 6000 K | 2,000 x 8 x 3 mm | |
| FXDL14W-3K5M | 14W/m | 1470 lm per metre | 110 lm/W | 3000 K | 5,000 x 8 x 3 mm | |
| FXDL14W-4K5M | 14W/m | 1470 lm per metre | 110 lm/W | 4000 K | 5,000 x 8 x 3 mm | |
| FXDL14W-6K5M | 14W/m | 1470 lm per metre | 110 lm/W | 6000 K | 5,000 x 8 x 3 mm |
FLEXIONSMOOTHLINE
Linear and Track
Seamless lighting solution.
Applications
Accent / Display / Feature Lighting, Boardroom / Meeting Rooms, Butler Pantry, Cabinetry, Cocktail Lounge, Ensuite, Games Rooms, Hallways, Hotel Rooms, Restaurants / Cafes, Retail Spaces, Showrooms, Staircase, Walk-in Wardrobes, Kitchen / Food Prep, Function Areas
Overview
For ambient or feature lighting, the new FLEXION SMOOTHLINE range offers integrated lighting solutions that produce bright, effective linear illumination. Endless flexibility is provided when combining the FLEXION SMOOTHLINE series with the new PARALLAX series of complementary aluminium profiles.
